Ctrl-Energy
19.4 Long-term measurement of the energy consumption
Turning
762 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
5. Press the "Graphic" softkey, to track the measurement characteristic.
6. If you want to track the consumption values, press the "Details" softkey.
7. Press the "Save measurement" softkey to save the consumption values
of the actual measurement.
The selection of the axis to be measured depends on the configuration.
References
Information on the configuration is provided in the following reference:
System Manual "Ctrl-Energy", SINUMERIK 840D sl / 828D
19.4 Long-term measurement of the energy consumption
The long-term measurement of energy consumption is performed in the PLC and saved. The
values from times in which the HMI is not active are also recorded.
Measured values
The infeed and regenerative power values as well as the sum of the power are displayed for
the following periods:
Current and previous day
Current and previous month
Current and previous year
Requirement
SENTRON PAC is connected.
Procedure
1. The "Ctrl-Energy Analysis" window opens.
2. Press the "Long-term measurement" softkey.
The "SINUMERIK Ctrl-Energy Analysis Long-term Measurement"
window opens.
The results of the long-term measurement are displayed.
4. Press the "Back" softkey to terminate the long-term measurement.
