Simulating machining
5.9 Editing and adapting a simulation graphic
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
193
5.9.2 Panning a graphical representation
Precondition
The simulation or the simultaneous recording is started.
Procedure
1. Press a cursor key if you wish to move the graphic up, down, left, or
right.
5.9.3 Rotating the graphical representation
In the 3D view you can rotate the position of the workpiece to view it from all sides.
Precondition
Simulation has been started and the 3D view is selected.
Procedure
1. Press the "Details" softkey.
2. Press the "Rotate view" softkey.
