Simulating machining
5.5 Different views of the workpiece
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
185
5.5.3 Face view
1. Start the simulation.
2. Press the "Other views" and "Face view" softkeys.
The side view shows the workpiece in the X-Y plane.
Changing the display
You can increase or decrease the size of the simulation graphic and move it, as well as
change the segment.
5.5.4 3D view
1. Start the simulation.
2. Press the "3D view" softkey.
Software option
You require the option "3D simulation (finished part)" for the simulation.
Changing the display
You can increase or decrease the size of the simulation graphic, move it, turn it, or change
the segment.
Displaying and moving cutting planes
You can display and move cutting planes X, Y, and Z.
See also
Defining cutting planes (Page 195)
