Alarm, error and system messages
13.9 Remote diagnostics
Turning
706 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Data Meaning
Send interval Cycle in which the message is sent to the remote PC in seconds
Ping send
data
Message for the remote PC
Procedure
1. The "Remote diagnostics (RCS)" window is opened.
2. Press the "Request remote diagnostics" softkey.
The "Request remote diagnostics" window is displayed.
3. Press the "Change" softkey if you would like to edit the values.
4. Press the "OK" softkey.
The request is sent to the remote PC.
References
Commissioning Manual SINUMERIK Operate (IM9) / SINUMERIK 840D sl
13.9.4 Exit remote diagnostics
Procedure
1. The "Remote diagnostics (RCS)" is opened and it is possible that
remote monitoring or remote access is active.
2. Block the modem access if access via modem is to be blocked.
- OR -
In the "Remote Diagnostics (RCS)" window, reset the access rights to
"Permit no remote access".
