Creating a G code program
6.6 Blank input
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
205
See also
Changing a cycle call (Page 215)
Selection of the cycles via softkey (Page 209)
Creating a new workpiece (Page 645)
6.6 Blank input
Function
The blank is used for the simulation and the simultaneous recording. A useful simulation can
only be achieved with a blank that is as close as possible to the real blank.
Create a separate program for each new workpiece that you would like to produce. The
program contains the individual machining steps that are performed to produce the
workpiece.
For the blank of the workpiece, define the shape (tube, cylinder, polygon or centered cuboid)
and your dimensions.
Manually reclamping the blank
If the blank is to be manually reclamped from the main spindle to the counterspindle for
example, then delete the blank.
Example
● Blank, main spindle, cylinder
● Machining
● M0 : Manually reclamping the blank
● Blank, main spindle, delete
● Blank, counterspindle, cylinder
● Machining
The blank entry always refers to the work offset currently effective at the position in the
program.
Note
Swiveling
For programs that use "Swiveling", a 0 swivel must first be made and then the blank defined.
