Ladder Viewer and Ladder add-on (828D only)
23.4 Control options
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
787
Screen element Display Meaning
Abs Absolute representation
5 Display of the active keys (<INPUT>, <SELECT>)
6 Focus
Performs the tasks of the cursor
7 Information line
Displays information, e.g. for searching
23.4 Control options
In addition to the softkeys and the navigation keys, there are further shortcuts in this area.
Shortcuts
The cursor keys move the focus over the PLC user program. When the window borders are
reached, scrolling is performed automatically.
Shortcuts Action
To the first column of the row
To the last column of the row
Up a screen
Down a screen
One field to the left, right, up or down
