Multi-channel machining (only 840D sl)
9.2 Multi-channel support (only 840D sl)
Turning
558 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
9.2.7 Synchronizing programs
Using the synchronized view, you have the possibility of obtaining an overview of the time
sequence of a program. In this case, program instructions are evaluated to coordinate
channels and are arranged in parallel in the editor view.
As a result of the synchronized view of the programs, you can easily identify at which
locations the programs are synchronized in the various channels.
Synchronizing commands
Commands Meaning
START Starts another program
WAITM Sets a mark and waits for the specified channels (with exact stop)
WAITMC Sets a mark and waits for the specified channels (without exact stop)
WAITE Waits for the end of program of the specified channels
SETM Sets a mark
CLEARM Clears a mark
GET Fetches an axis
RELEASE Releases an axis
Note
Identifying program errors
The error can only be identified if the appropriate program is displayed. If a WAIT mark
involves a channel to which a program is not assigned in the job list, then this is marked as
having an error.
If you have enabled the synchronized view, then the following symbols are displayed at the
top right in the program title bar:
Symbol Meaning
Synchronized view: Error
Errors were identified after enabling "synchronized view" or new
"synchronization" (e.g. WAIT marks not found in other programs).
Synchronized view: checked
No error was detected after enabling "synchronized view" or new
"synchronization".
