Tool management
11.8 Magazine
Turning
612 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Procedure
1. Select the "Parameter" operating area.
2. Press the "Magazine” softkey.
See also
Displaying tool details (Page 620)
Changing the cutting edge position or tool type (Page 622)
11.8.1 Positioning a magazine
You can position magazine locations directly on the loading point.
Procedure
1. The magazine list is opened.
2. Place the cursor on the magazine location that you want to position
onto the load point.
3. Press the "Position magazine" softkey.
The magazine location is positioned on the loading point.
Multiple load points
If you have configured several loading points for a magazine, then the "Load Point Selection"
window appears after pressing the "Position magazine" softkey.
Select the desired loading point in this window and confirm your selection with "OK" to
position the magazine location at the loading point.
