Managing programs
12.1 Overview
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
639
Creating Directories
1. The local drive is selected.
2. Position the cursor on the main directory.
3. Press the "New" and "Directory" softkeys.
The "New Directory" window opens.
4. In the "Name" entry field, enter "mpf.dir", "spf.dir" and "wks.dir" and
press the "OK" softkey.
The directories "Part programs", "Subprograms" and "Workpieces" are
created below the main directory.
12.1.4 USB drives
USB drives enable you to exchange data. For example, you can copy to the NC and execute
programs that were created externally.
NOTICE
Interruption of operation
Direct execution from the USB FlashDrive is not recommended, because machining can be
undesirably interrupted, therefore resulting in workpiece damage.
Partitioned USB-FlashDrive (only 840D sl and TCU)
If the USB-FlashDrive has several partitions, these are displayed in a tree structure as a
subtree (01,02,...).
For EXTCALL calls, enter the partition (e.g. USB:/02/... or //ACTTCU/FRONT/02/... or
//ACTTCU/FRONT,2/... or //TCU/TCU1/FRONT/02/...)
You can also configure any partition (e.g. //ACTTCU/FRONT,3).
