Managing programs
12.2 Opening and closing the program
Turning
642 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
- OR -
Press the <Cursor right> key.
- OR -
Double-click the program.
The selected program is opened in the "Editor" operating area.
4. Now make the necessary program changes.
5. Press the "NC Select" softkey to switch to the "Machine" operating area
and begin execution.
When the program is running, the softkey is deactivated.
Closing the program
Press the ">>" and "Exit" softkeys to close the program and editor again.
- OR -
If you are at the start of the first line of the program, press the <Cursor left>
key to close the program and the editor.
To reopen a program you have exited with "Close", press the "Program" key.
Note
A program does not have to be closed in order for it to be executed.
