Managing programs

12.16 Setup data

Turning

Operating Manual, 03/2013, 6FC5398-8CP40-3BA1

679

Procedure

1. Select the "Program Manager" operating area.

2. Position the cursor on the file with the backed-up tool and zero point

data (*.INI) that you wish to re-import.

3. Press the <Cursor right> key

- OR -

Double-click the file.

The "Read-in setup data" window opens.

4. Select the data (e.g. magazine assignment) that you wish to read-in.

5. Press the "OK" softkey.
