Programming technology functions (cycles)
8.1 Drilling
Turning
308 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Parameter Description Unit
Position
(only for
ShopTurn)
• At the front (face)
• At the rear (face)
• Outside (peripheral surface)
• Inside (peripheral surface)
Position pattern
Selection option for the following patterns:
• Line
• Matrix
• Box
X0
Y0
α0
(only for G-Code)
X coordinate of the reference point X (abs)
This position must be programmed absolutely in the 1st call.
Y coordinate of the reference point Y (abs)
This position must be programmed absolutely in the 1st call.
Angle of rotation of the line referred to the X axis
Positive angle: Line is rotated counterclockwise.
Negative angle: Line is rotated clockwise.
mm
mm
Degrees
Z0
X0
Y0
α0
(only for
ShopTurn)
Face C:
Z coordinate of the reference point (abs)
X coordinate of the reference point – first position (abs)
Y coordinate of the reference point – first position (abs)
Angle of rotation of line in relation to the X axis
Positive angle: Line is rotated counterclockwise.
Negative angle: Line is rotated clockwise.
mm
mm
mm
Degrees
Z0
CP
X0
Y0
α0
(only for
ShopTurn)
Face Y:
Z coordinate of the reference point (abs)
Positioning angle for machining area
X coordinate of the reference point – first position (abs)
Y coordinate of the reference point – first position (abs)
Angle of rotation of line in relation to the X axis
Positive angle: Line is rotated counterclockwise.
Negative angle: Line is rotated clockwise.
mm
Degrees
mm
mm
Degrees
X0
Y0
Z0
α0
(only for
ShopTurn)
Peripheral surface C:
Cylinder diameter ∅ (abs)
Y coordinate of the reference point – first position (abs)
Z coordinate of the reference point – first position (abs)
Angle of rotation of line with reference to Y axis
Positive angle: Line is rotated counterclockwise.
Negative angle: Line is rotated clockwise.
mm
mm
mm
Degrees
