Siemens SINUMERIK 828D Turning User Manual

Creating a ShopTurn program
7.16 Programming the approach/retraction cycle
Turning
256 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Table 7- 1
Parameters Description Unit
F1 Feedrate to approach the first position
Alternatively, rapid traverse
mm/min
X1 1. position ∅ (abs) or 1st position (inc) mm (in)
Z1 1. position (abs or inc) mm
F2 Feedrate for approach to the second position
Alternatively, rapid traverse
mm/min
X2 2. position ∅ (abs) or 2nd position (inc) mm
Z2 2. position (abs or inc) mm
F3 Feedrate to approach the third position
Alternatively, rapid traverse
mm/min
X3 3. position ∅ (abs) or 3rd position (inc) mm
Z3 3. position (abs or inc) mm
Tool change TlChngPt: Approach the tool change point from the last programmed position and
carry out a tool change
direct: Tool is not changed at the tool change position, but at the last programmed
position
No: Tool is not changed
T Tool name - (only for "direct" tool change)
D Cutting edge number - (only for "direct" tool change)
F4 Feedrate for approach to the fourth position
Alternatively, rapid traverse
mm/min
X4 4. position ∅ (abs) or 4th position (inc) mm
Z4 4. position (abs or inc) mm
F5 Feedrate to approach the fifth position
Alternatively, rapid traverse
mm/min
X5 5. position ∅ (abs) or 5th position (inc) mm
Z5 5. position (abs or inc) mm
F6 Feedrate to approach the sixth position
Alternatively, rapid traverse
mm/min
X6 6. position ∅ (abs) or 6th position (inc) mm
Z6 6. position (abs or inc) mm
