Introduction
1.2 Operator panel fronts
Turning
28 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
<Cursor left>
• Editing box
Closes a directory or program (e.g. cycle) in the program editor.
If you have made changes, then these are accepted.
• Navigation
Moves the cursor further to the left by one character.
<Cursor left> + <CTRL>
• Editing box
Moves the cursor further to the left by one word.
• Navigation
Moves the cursor in a table to the next cell to the left.
<Cursor up>
• Editing box
Moves the cursor into the next upper field.
• Navigation
– Moves the cursor in a table to the next cell upwards.
– Moves the cursor upwards in a menu screen.
<Cursor up> + <CTRL>
• Moves the cursor in a table to the beginning of the table.
• Moves the cursor to the beginning of a window.
<Cursor up> + <SHIFT>
In the program manager and in the program editor, selects a
contiguous selection of directories and program blocks.
<Cursor down>
• Editing box
Moves the cursor downwards.
• Navigation
– Moves the cursor in a table to the next cell downwards.
– Moves the cursor in a window downwards.
<Cursor down> + <CTRL>
• Navigation
– Moves the cursor in a table to the end of the table.
– Moves the cursor to the end of a window.
• Simulation
Reduces the override.
