Programming technology functions (cycles)
8.1 Drilling
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
291
Parameter Description Unit
Machining
position (only
for G code)
• Single position
Drill hole at programmed position
• Position pattern
Position with MCALL
Z0 (only for G
code)
Reference point Z mm
Machining
surface
(only for
ShopTurn)
• Face C
• Face Y
• Peripheral surface C
• Peripheral surface Y
Position
(only for
ShopTurn)
• At the front (face)
• At the rear (face)
• Outside (peripheral surface)
• Inside (peripheral surface)
(only for
ShopTurn)
Clamp/release spindle
The function must be set up by the machine manufacturer.
Machining
• Swarf removal
The drill is retracted from the workpiece for swarf removal.
• Chipbreaking
The drill is retracted by the retraction distance V2 for chipbreaking.
Drilling depth
• Shank (drilling depth in relation to the shank)
The drill is inserted into the workpiece until the drill shank reaches the value
programmed for Z1. The angle entered in the tool list is taken into account.
• Tip (drilling depth in relation to the tip)
The drill is inserted into the workpiece until the drill tip reaches the value
programmed for Z1.
Note: If it is not possible to define an angle for the drill in the tool management, it will
not be possible to select tip or shank (always tip, 0 field)
Z1
Drilling depth (abs) or drilling depth in relation to Z0 (inc)
It is inserted into the workpiece until it reaches Z1.
mm
D
(only for G code)
1. Drilling depth (abs) or 1st drilling depth in relation to Z0 (inc) mm
D (only for
ShopTurn)
Maximum depth infeed mm
FD1 Percentage for the feedrate for the first infeed %
