Programming technology functions (cycles)
8.1 Drilling
Turning
298 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Parameter Description Unit
SDE
(only for G code)
Direction of rotation after end of cycle:
•
•
•
Technology
• Yes
– Exact stop
– Precontrol
– Acceleration
– Spindle
• No
Exact stop (only
for technology,
yes)
• Behavior the same as it was before the cycle was called
• G601: Block advance for exact stop fine
• G602: Block advance for exact stop coarse
• G603: Block advance if the setpoint is reached
Precontrol (only
for technology,
yes)
• Behavior the same as it was before the cycle was called
• FFWON: with precontrol
• FFWOF: without precontrol
Acceleration (only
for technology,
yes)
• Behavior the same as it was before the cycle was called
• SOFT: Jerk-limited (soft) acceleration of the axes
• BRISK: Abrupt acceleration of the axes
• DRIVE: Reduced axis acceleration
Spindle (only for
technology, yes)
• Speed controlled: Spindle for MCAL; speed controlled operation
• Position controlled: Spindle for MCALL; position controlled operation
