Programming technology functions (cycles)
8.1 Drilling
Turning
300 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Procedure
1. The part program or ShopTurn program to be processed has been
created and you are in the editor.
2. Press the "Drilling" softkey.
3. Press the "Thread" and "Cut thread" softkeys.
The "Drilling and thread milling" input window opens.
Parameters, G code program Parameters, ShopTurn program
PL
Machining plane T Tool name
RP Retraction plane mm D Cutting edge number
SC Safety clearance mm F
Feedrate mm/min
mm/rev
S / V
Spindle speed or constant
cutting rate
rpm
m/min
Parameters Description Unit
Machining
position
(only for G code)
• Single position
Drill hole at programmed position
• Position pattern
Position with MCALL
F1
(only for G code)
Drilling feedrate mm/min
mm/rev
Z0
(only for G code)
Reference point Z mm
Machining
surface
(only for
ShopTurn)
• Face C
• Face Y
• Peripheral surface C
• Peripheral surface Y
Position
(only for
ShopTurn)
• At the front (face)
• At the rear (face)
• Outside (peripheral surface)
• Inside (peripheral surface)
