Programming technology functions (cycles)
8.1 Drilling
Turning
314 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
4. Press the "Hide position" softkey.
The "Hide position" window opens on top of the input form of the
position pattern.
The positions are displayed in a table.
The numbers of the positions, their coordinates (X, Y) as well as a
checkbox with the state (activated = on / deactivated = off) are
displayed.
The actual position in the graphic is highlighted in color.
5. Using the mouse, select the required position and deactivate or activate
the checkbox in order to hide the position or display it again.
In the diagram, skipped positions are shown in the form of a circle and
displayed (active) positions are shown in the form of a cross.
Note: You have the option of selecting individual positions using the
<Cursor up> or <Cursor down> keys – and hiding and displaying using
the <SELECT> key.
Display or hide all positions at once
1. Press the "Hide all" softkey to hide all positions.
2. Press the "Show all" softkey to display all positions again.
