Programming technology functions (cycles)
8.2 Rotate
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
339
Parameter Description Unit
P2 Thread pitch 3 (unit as parameterized for P0) mm/rev
in/rev
turns/"
MODULUS
X3
• End point X ∅ (abs) or
• End point 3 in relation to X2 (inc) or
• Thread taper 3
mm
Degrees
Z3
• End point Z ∅ (abs) or
• End point with reference to Z2 (inc)
mm
LW Thread run-in mm
LR Thread run-out mm
H1 Thread depth mm
DP or αP Infeed slope (flank) or infeed slope (angle) mm or
degrees
• Infeed along a flank
• Infeed with alternating flanks
D1 or ND First infeed depth or number of roughing cuts - (only for ∇ and ∇ + ∇∇∇) mm
U Finishing allowance in X and Z - (only for ∇ and ∇ + ∇∇∇) mm
NN Number of noncuts - (only for ∇∇∇ and ∇ + ∇∇∇)
VR Return distance mm
No
α0 Starting angle offset Degrees
Yes
N Number of thread turns
Multiple threads
DA Thread changeover depth (inc) mm
