Programming technology functions (cycles)
8.2 Rotate
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
341
Parameters, G code program Parameters, ShopTurn program
PL Machining plane T Tool name
SC Safety clearance mm D Cutting edge number
F Feedrate * F Feedrate mm/rev
S / V
Spindle speed or constant
cutting rate
rpm
m/min
Parameter Description Unit
DIR
(only for G code)
Direction of spindle rotation
S Spindle speed rev/min
V Constant cutting rate m/min
SV Maximum speed limit - (only for constant cutting rate V) rev/min
X0 Reference point in X ∅ (abs, always diameter) mm
Z0 Reference point in Z (abs) mm
FS or R Chamfer width or rounding radius mm
X1 Depth for speed reduction ∅ (abs) or depth for speed reduction in relation to X0
(inc)
mm
FR
(only for ShopTurn)
Reduced feedrate mm/rev
FR
(only for G code)
*
SR Reduced speed rev/min
X2 Final depth ∅ (abs) or final depth in relation to X1 (inc) mm
* Unit of feedrate as programmed before the cycle call
