Programming technology functions (cycles)
8.3 Contour turning
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
359
Parameters, G code program Parameters, ShopTurn program
PRG Name of the program to be
generated
T Tool name
PL Machining plane D Cutting edge number
RP Retraction plane –
(only for machining
direction,
longitudinal, inner)
mm F Feed (∇ or ∇∇∇) mm/rev
SC Safety clearance mm FS Finishing feedrate (only
for complete machining:
∇ + ∇∇∇)
mm/rev
F Feed (∇ or ∇∇∇) * S / V
Spindle speed or
constant cutting rate
m/min
FS Finishing feedrate
(only for complete
machining: ∇ + ∇∇∇)
*
Residual
material
With subsequent residual material
removal
• Yes
• No
CONR Name to save the updated blank
contour for residual material
removal
Parameter Description Unit
Machining
• ∇ (roughing)
• ∇∇∇ (finishing)
• ∇ + ∇∇∇ (roughing and finishing)
• Face
• Longitudinal
• Parallel to the contour
• From inside to outside
• From outside to inside
• From end face to rear side
• From rear side to end face
Machining
direction
The machining direction depends on the stock removal direction and choice of tool.
