Programming technology functions (cycles)
8.4 Milling
Turning
400 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Parameter Description Unit
CP
X0 or L0
Y0 or C0
Z0
(only for
ShopTurn)
Face Y: The positions refer to the reference point:
Positioning angle for machining area – (only single position)
Reference point X or reference point length polar – (only for single position)
Reference point Y or reference point angle polar – (only for single position)
Reference point Z – (only for single position)
Degrees
mm
mm or
degrees
mm
Y0 or C0
Z0
X0
(only for
ShopTurn)
Peripheral surface C: The positions refer to the reference point:
Reference point Y or reference point angle polar - (only for single position)
Reference point Z - (only for single position)
Cylinder diameter ∅ – (only for single position)
mm or
degrees
mm
mm
C0
Y0
Z0
X0
(only for
ShopTurn)
Peripheral surface Y: The positions refer to the reference point:
Positioning angle for machining surface – (only for single position)
Reference point Y – (only for single position)
Reference point Z – (only for single position)
Reference point X – (only for single position)
Degrees
mm
mm
mm
∅ Diameter of spigot mm
Z1
Spigot depth (abs) or depth relative to Z0 or X0 (inc) - (only for ∇ and ∇∇∇) mm
DZ Maximum depth infeed - (only for ∇ and ∇∇∇) mm
UXY Plane finishing allowance for the length (L) and width (W) of the circular spigot.
Smaller circular spigot dimensions are obtained by calling the cycle again and
programming it with a lower finishing allowance. - (only for ∇ and ∇∇∇)
mm
UZ Depth finishing allowance (tool axis) - (only for ∇ and ∇∇∇) mm
∅1 Diameter of blank spigot (important for determining approach position) - (only for ∇ and
∇∇∇)
mm
FS Chamfer width for chamfering - (for chamfering only) mm
ZFS
Insertion depth of tool tip (abs or inc) - (for chamfering only)
(ZFS for machining surface, face C/Y or XFS for peripheral surface C/Y)
mm
* Unit of feedrate as programmed before the cycle call
