Programming technology functions (cycles)
8.5 Contour milling
Turning
446 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Parameters Description Unit
β1 End angle to Z axis Degrees
β2 Opening angle Degrees
Transition to next
element
Type of transition
• Radius
• Chamfer
Radius R Transition to following element - radius mm
Chamfer FS Transition to following element - chamfer mm
Additional commands Additional G code commands
Contour element "Pole"
Parameters Description Unit
Machining
surface
(only for ShopTurn)
• Face C
• Face Y
• Face B
• Peripheral surface C
• Peripheral surface Y
X
Y
Position pole (abs)
Position pole (abs)
mm (in)
Degrees
Contour element "End"
The data for the transition at the contour end of the previous contour element is displayed in
the "End" parameter screen.
The values cannot be edited.
