Programming technology functions (cycles)
8.5 Contour milling
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
453
Parameter Description Unit
C0 Positioning angle for machining surface
- (only for ShopTurn, machining surface, peripheral surface Y)
Degrees
Z0 Reference point Z mm
Z1 Final drilling depth (abs) or final drilling depth referred to Z0 or X0 (inc) mm
DZ Maximum depth infeed - (only for machining ∇ and ∇∇∇) mm
UZ Depth finishing allowance - (only for machining ∇) mm
UXY Finishing allowance, plane mm
Approach
Planar approach mode:
• Quadrant:
Part of a spiral (only with path milling left and right of the contour)
• Semi-circle:
Part of a spiral (only with path milling left and right of the contour)
• Straight line:
Slope in space
• Perpendicular:
Perpendicular to the path (only with path milling on the center-point path)
Approach strategy
• axis-by-axis - (only for "quadrant, semi-circle or straight line" approach)
• spatial - (only for "quadrant, semi-circle or straight line" approach)
R1 Approach radius - (only for "quadrant or semi-circle" approach) mm
L1 Approach distance - (only for "straight line" approach) mm
FZ
(only for G code)
Depth infeed rate *
FZ
(only for
ShopTurn)
Depth infeed rate mm/min
mm/tooth
Retraction
Planar retraction mode:
• Quadrant:
Part of a spiral (only with path milling left and right of the contour)
• Semi-circle:
Part of a spiral (only with path milling left and right of the contour)
• Straight line:
