Multi-channel machining (only 840D sl)
9.1 Multi-channel view (only 840D sl)
Turning
528 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Single-channel view
If, for your multi-channel machine, you always only wish to monitor one channel, then you
can set a permanent single-channel view.
Horizontal softkeys
● Block search
When selecting the block search, the multi-channel view is kept. The block display is
displayed as search window.
● Program control
The "Program Control" window is displayed for the channels configured in the multi-
channel view. The data entered here applies for these channels together.
● If you press an additional horizontal softkey in the "Machine" operating area (e.g.
"Overstore", "Synchronized actions"), then you change into a temporary single-channel
view. If you close the window again, then you return to the multi-channel view.
Switching between single- and multi-channel view
Press the <MACHINE> key in order to briefly switch between the single-
and multi-channel view in the machine area.
Press the <NEXT WINDOW> key in order to switch between the upper
and lower window within a channel column.
Editing a program in the block display
You can perform simple editing operations as usual with the <INSERT>
key in the actual block display.
If there is not sufficient space, you switch over into the single-channel view.
Running-in a program
You select individual channels to run-in the program at the machine.
Requirement
● Several channels have been set-up.
● The setting "2 channels", "3 channels" or "4 channels" is selected.
