Multi-channel machining (only 840D sl)
9.1 Multi-channel view (only 840D sl)
Turning
532 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Example
Your machine has 6 channels.
You configure channels 1 - 4 for the multi-channel view and define the display sequence
(e.g. 1,3,4,2).
In the multi-channel view, for a channel switchover, you can only switch between the
channels configured for the multi-channel view; all others are not taken into consideration.
Using the <CHANNEL> key, advance the channel in the "Machine" operating area - you
obtain the following views: Channels "1" and "3", channels "3" and "4", channels "4" and "2".
Channels "5" and "6" are not displayed in the multi-channel view.
In the single-channel view, toggle between all of the channels (1...6) without taking into
account the configured sequence for the multi-channel view.
Using the channel menu, you can always select all channels, also those not configured for
multi-channel view. If you switch to another channel, which is not configured for the multi-
channel view, then the system automatically switches into the single-channel view. There is
no automatic switchback into the multi-channel view, even if a channel is again selected,
which has been configured for multi-channel view.
Procedure
1. Select the "Machine" operating area.
2. Select the "JOG", "MDA" or "AUTO" mode.
3. Press the menu forward key and the "Settings" softkey.
4. Press the "Multi-channel view" softkey.
The "Settings for Multi-Channel View" window is opened.
5. Set the multi-channel or single-channel view and define which channels
are to be seen in the "Machine" operating area - and in the editor - in
which sequence.
