Multi-channel machining (only 840D sl)
9.2 Multi-channel support (only 840D sl)
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
555
Settings for a program block
Display Meaning
Text Block designation
Spindle
• S1
• S2
Spindle assignment. Defines at which spindle a program block is to be
executed.
Addit. run-in code
• Yes
If the block is not to be executed, because the specified spindle is not to
be used, it is possible to temporarily activate a so-called "Addit. run-in
code".
• No
Automat. retraction
• Yes
Block start and block end are moved to the tool change point, i.e. the tool
is brought into a safe range.
• No
Procedure
1. Select the "Program manager" operating area.
2. Select the storage location and create a program or open a program.
The program editor opens.
3. Select the required program blocks, which you wish to combine to form
a block.
4. Press the "Build group" softkey.
The "Build group" window is opened.
5. Enter a designation for the block, assign the spindle, if required, select
the Addit. run-in code and the automatic retraction and then press the
"OK" softkey.
