Tool management

11.4 Tool dimensioning

Turning

588 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1

Machine manufacturer

The tool length is measured to the center of the ball or to the ball

circumference.

Please refer to the machine manufacturer's specifications.

Note

A 3D probe must be calibrated before use.
