Tool management
11.5 Tool list
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
599
Enter the location number you require and press the "OK" softkey.
- OR -
Press the "Spindle" softkey.
. The tool is loaded into the specified magazine location or spindle.
Several magazines
If you have configured several magazines, the "Load to ..." window appears after pressing
the "Load" softkey.
If you do not want to use the suggested empty location, then enter your desired magazine
and magazine location. Confirm your selection with "OK".
Multiple load points
If you have configured several loading points for a magazine, then the "Load Point Selection"
window appears after pressing the "Load" softkey.
Select the required loading point and confirm with "OK".
Unloading tools
1. Place the cursor on the tool that you would like to unload from the
magazine and press the "Unload" softkey.
2. Select the required load point in the "Load Point Selection" window.
3. Confirm your selection with "OK".
- OR -
Undo your selection with "Cancel".
