Tool management
11.6 Tool wear
Turning
606 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Icons in the tool wear list
Icon/
Marking
Meaning
Tool type
Red "X"
The tool is disabled.
Yellow triangle pointing
downward
The prewarning limit has been reached.
Yellow triangle pointing
upward
The tool is in a special state.
Place the cursor on the marked tool. A tooltip provides a
short description.
Green border
The tool is preselected.
Magazine/location number
Green double arrow
The magazine location is positioned at the change position.
Gray double arrow
(configurable)
The magazine location is positioned at the loading position.
Red "X"
The magazine location is disabled.
Procedure
1. Select the "Parameter" operating area.
2. Press the "Tool wear" softkey.
See also
Displaying tool details (Page 620)
Changing the cutting edge position or tool type (Page 622)
