Setting up the machine
2.3 Modes and mode groups
Turning
66 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Selecting "Repos"
Press the <REPOS> key.
"MDI" mode (Manual Data Input)
In "MDI" mode, you can enter and execute G code commands non-modally to set up the
machine or to perform a single action.
Selecting "MDI"
Press the <MDI> key.
"AUTO" mode
In automatic mode, you can execute a program completely or only partially.
Select "AUTO"
Press the <AUTO> key.
"TEACH IN" operating mode
"TEACH IN" is available in the "AUTO" and "MDI" operating modes.
There you may create, edit and execute part programs (main programs or subroutines) for
motional sequences or simple workpieces by approaching and saving positions.
Selecting "Teach In"
Press the <TEACH IN> key.
