Siemens SINUMERIK 828D Turning User Manual

Working with a B axis (only 840D sl)
15.1 Lathes with B axis
Turning
726 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Alignment angles β and γ
Alignment angles β and γ are required for turning with tool alignment.
;
=
˟
ˠ
β: Rotation around the Y axis (with the B axis)
γ: Rotation around the Z axis (with the tool spindle)

Siemens SINUMERIK 828D Turning Specifications

General

Brand	Siemens
Model	SINUMERIK 828D Turning
Category	Controller
Language	English
