Siemens SINUMERIK 828D User Manual

Creating a ShopTurn program
8.18 Example: Standard machining
Turning
280 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
7. Stock removal (finishing)
1.
Press the "Cont. turn." and "Stock removal" softkeys.
The "Stock Removal" input window opens.
2.
Enter the following technology parameters:
T Finishing tool_D1
F 0.1 mm/rev
V 450 m/min
3.
Enter the following parameters:
Machining
Finishing (∇∇∇)
Machining direction
Longitudinal
Position
outside
Machining direction
(from the face to the rear side)
Allowance
No
Relief cuts
Yes
Set machining area limits
No
4.
Press the "Accept" softkey.
8. Groove (roughing)
1.
Press the "Turning", "Groove" and "Groove with inclines" softkeys.
The "Groove 1" entry field opens.
2.
Enter the following technology parameters:
T
Grooving
tool
D1
F
0.150 mm/rev
V
220 m/min
3.
Enter the following parameters:
Machining
Roughing (∇)
Groove position
Reference point
X0
60
abs
Z0
-70
B2
8
inc
T1
4
inc
