Creating a ShopTurn program

8.18 Example: Standard machining

Turning

282 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2

9. Groove (finishing)

Press the "Turning", "Groove" and "Groove with inclines" softkeys.

The "Groove 2" entry field opens.

Enter the following technology parameters:

T Grooving tool

F 0.1 mm/rev

V 220 m/min

Enter the following parameters:

Machining

Finishing (∇∇∇)

Groove position

Reference point

abs

-70

5.856

inc

α1

degrees

α2

degrees

FS1

FS4

Press the "Accept" softkey.
