Creating a ShopTurn program

8.18 Example: Standard machining

Turning

Operating Manual, 01/2015, 6FC5398-8CP40-5BA2

283

10. Longitudinal threads M48 x2 (roughing)

Press the "T

urning", "Thread" and "Thread longitudinal" softkeys.

The "Longitudinal thread" entry field opens.

Enter the following parameters:

Threading tool_2

Table

without

mm/rev

995

rev/min

Machining type

Roughing (∇)

Infeed: Constant cutting

cross-section

Diminishing

Thread

External thread

abs

-25

abs

inc

1.227

inc

αP

degrees

Infeed

0.150

inc

Multiple threads

α0

degrees

Press the "Accept" softkey.
