Creating a ShopTurn program

8.18 Example: Standard machining

Turning

286 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2

14. Milling the rectangular pocket

Press the "Milling", "Pocket" and "Rectangular pocket" softkeys.

The "Rectangular Pocket" input window opens.

Enter the following technology parameters:

T Miller_D8

F 0.030 mm/tooth

V 200 m/min

Enter the following parameters:

Machined surface

Face C

Machining type

Roughing (∇)

Machining position

Single position

abs

α0

Degrees

inc

DXY

UXY

0.1

Insertion

Vertical

0.015

mm/tooth

Press the "Accept" softkey.
