Programming technology functions (cycles)
9.1 Drilling
Turning
324 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Approach/retraction CYCLE84 - without compensating chuck in the "swarf removal" mode
1. The tool drills at the programmed spindle speed S (dependent on %S) as far as the 1st
infeed depth (maximum infeed depth D).
2. Spindle stop and dwell time DT.
3. The tool retracts from the workpiece for the stock removal with spindle speed SR to the
safety clearance.
4. Spindle stop and dwell time DT.
5. The tool then drills with spindle speed S as far as the next infeed depth.
6. Steps 2 to 5 are repeated until the programmed final drilling depth Z1 is reached.
7. On expiry of dwell time DT, the tool is retracted with spindle speed SR to the safety
clearance. The spindle stops and retracts to the retraction plane.
Approach/retraction CYCLE84 - without compensating chuck in the "chip breaking" mode
1. The tool drills at the programmed spindle speed S (dependent on %S) as far as the 1st
infeed depth (maximum infeed depth D).
2. Spindle stop and dwell time DT.
3. The tool retracts by the retraction distance V2 for chip breaking.
4. The tool then drills to the next infeed depth at spindle speed S (dependent on %S).
5. Steps 2 to 4 are repeated until the programmed final drilling depth Z1 is reached.
6. On expiry of dwell time DT, the tool is retracted with spindle speed SR to the safety
clearance. The spindle stops and retracts to the retraction plane.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Procedure
1.
The part program or ShopTurn program to be processed
has been cre-
ated and you are in the editor.
2.
Press the "Drilling" softkey.
3.
Press the "Thread" and "Tapping" softkeys.
The "Tapping" input window opens.
