Programming technology functions (cycles)
9.1 Drilling
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
325
Parameters in the "Input complete" mode
G code program parameters
ShopTurn program parameters
Input (only for G code)
• Complete
PL
Machining plane T Tool name
RP
Retraction plane
mm
D
Cutting edge number
SC Safety clearance mm S / V
Spindle speed or constant cut-
ting rate
rpm
m/min
Parameter
Description
Unit
Compensating
chuck mode
• with compensating chuck
• without compensating chuck
Machining posi-
tion
(only for G
code)
• Single position
Drill hole at programmed position
• Position pattern
Position with MCALL
Z0 (only for G
code)
Reference point Z mm
Machining - (with
compensating
chuck)
You can select the following technologies for tapping:
• with encoder
Tapping with spindle encoder
• without encoder
Tapping without spindle encoder - the following fields are displayed:
– Select the "pitch" parameter (only G code)
– Enter parameter "DT" (only ShopMill)
Note:
For ShopMill, the selection box is only displayed if tapping without encoder is enabled.
Please observe the information provided by your machine manufacturer.
SR (only for
ShopTurn)
Spindle speed for retraction - (only for spindle speed "S") rev/min
VR (only for
ShopTurn)
Constant cutting rate for retraction - (only for constant cutting rate "V") m/min
Machining
surface
(only for Shop-
Turn)
• Face C
• Face Y
• Face B
• Peripheral surface C
• Peripheral surface Y
