Siemens SINUMERIK 828D - Page 339

Programming technology functions (cycles)
9.1 Drilling
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
339
Parameter
Description
Unit
LAB
(only for G code)
Repeat jump label for position
PL
(only for G code)
Machining plane
Axes
(only for G code)
Selection of the participating axes
• XY (1st and 2nd axis of the plane)
• ZC (rotary axis and assigned linear axis)
• YZC (rotary axis and both axes of the plane)
Note
:
Rotary axes are only displayed in the selection field if they have
been released for use in the position pattern.
Please observe the information provided by your machine manufac-
turer.
Machining
surface
(only for ShopTurn)
• Face C
• Face Y
• Face B
• Peripheral surface C
• Peripheral surface Y
Position
(only for ShopTurn)
• At the front (face)
• At the rear (face)
• Outside (peripheral surface)
• Inside (peripheral surface)
Coordinate
system
(only for ShopTurn)
• Right-angled or polar
Dimensions in right-angled coordinates or polar coordinates (on-
ly for face C and face Y)
• Right-angled or cylindrical
Dimensions in right-angled coordinates or cylindrical coordinates
- (only for peripheral surface C)
X0
Y0
X1
...X8
Y1 ...Y8
(only for G code)
Axes XY (at right angles)
X coordinate of 1st position (abs)
Y coordinate of 1st position (abs)
X coordinate for additional positions (abs or inc)
Y coordinate for additional positions (abs or inc)
mm
mm
mm
mm
Z0
C0
Z1
... Z8
C1 ...C8
(only for G code)
Axes ZC (for G19
)
Z coordinate of 1st position (abs)
C coordinate of 1st position (abs)
Z coordinates for additional positions (abs or inc)
C coordinates for additional positions (abs or inc)
mm
Degrees
mm
Degrees
