Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.3 Contour turning
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
407
G code program parameters
ShopTurn program parameters
Input
• Complete
PRG
Name of the program to be generated
T
Tool name
PL
Machining plane
D
Cutting edge number
RP Retraction plane – (only for
machining direction, longi-
tudinal, inner)
mm F Feedrate mm/rev
SC Safety clearance mm S / V
Spindle speed or constant cutting
rate
m/min
F
Feedrate
*
Residual
material
With subsequent residual material removal.
• Yes
• No
CONR Name to save the updated blank contour for
residual material removal
Parameter
Description
Unit
Machining
• ∇ (roughing)
• ∇∇∇ (finishing)
• ∇+∇∇∇ (complete machining)
Machining
direction
• Face
• Longitudinal
•
Parallel to the contour
• From inside to outside
• From outside to inside
• From end face to rear side
• From rear side to end face
The machining direction depends on the stock removal direction and choice of tool.
Position
• Front
• Rear
• Inside
• Outside
