2.4 User interface

Turning

Operating Manual, 01/2015, 6FC5398-8CP40-5BA2

Active operating area

Display

Description

"Machine" operating area

With touch operation, you can change the operating area here.

"Parameter" operating area

"Program" operating area

"Program manager" operating area

"Diagnosis" operating area

"Start-up" operating area

Active mode or submode

Display

Description

"Jog" mode

"MDA" mode

"Auto" mode

"Teach In" submode

"Repos" submode

"Ref Point" submode
