Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.4 Milling
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
433
Parameters, G code program
Parameters, ShopTurn program
PL
Machining plane T Tool name
RP Retraction plane mm F
Feedrate mm/min
mm/tooth
SC Safety clearance mm S / V
Spindle speed or constant cut-
ting rate
rpm
m/min
F
Feedrate
*
parameters
Description
Unit
Machining surface
(only for Shop-
Turn)
• Face Y
• Peripheral surface Y
(only for Shop-
Turn)
Clamp/release spindle
The function must be set up by the machine manufacturer.
Machining
The following machining technologies can be selected:
• ∇ (roughing)
• ∇∇∇ (finishing)
Direction
Same direction of machining
•
•
Alternating direction of machining
•
•
(only for G code)
X0
Y0
Z0
X1
Y1
Z1
The positions refer to the reference point:
Corner point 1 in X
Corner point 1 in Y
Height of blank
Corner point 2X (abs) or corner point 2X in relation to X0 (inc)
Corner point 2Y (abs) or corner point 2Y in relation to Y0 (inc)
Height of blank (abs) or height of blank in relation to Z0 (inc)
mm
mm
mm
mm
mm
mm

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
