Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.4 Milling
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
451
Parameter
Description
Unit
ER Radius of helix - (only for helical insertion)
The radius must not be larger than the milling cutter radius, otherwise material will
remain. Also make sure the circular pocket is not violated.
mm
Solid machining
(only for G code)
•
Complete machining
The circular pocket must be milled from a solid workpiece (e.g. casting).
•
Post machining
A small pocket or hole has already been machined in the workpiece, which needs
to be enlarged. Parameters AZ, and ∅1 must be programmed.
FS
Chamfer width for chamfering - (for chamfering only)
mm
ZFS Insertion depth of tool tip (abs or inc) - (for chamfering only) mm
AZ
(only for G code)
Depth of premachining - (for remachining only) mm
∅1
(only for G code)
Diameter of premachining - (for remachining only) mm
* Unit of feedrate as programmed before the cycle call
Parameters in the "Input simple" mode
G code program parameters
ShopTurn program parameters
Input
• simple
Milling direction
T
Tool name
RP
Retraction plane
mm
D
Cutting edge number
F Feedrate * F Feedrate mm/min
mm/rev
S / V Spindle speed or constant
cutting rate
rpm
m/min
Parameter
Description
Machining
surface (only for
ShopTurn)
• Face C
• Face Y
• Peripheral surface C
• Peripheral surface Y
Position (only for
ShopTurn)
• At the front (face)
• At the rear (face)
• Outside (peripheral surface)
• Inside (peripheral surface)

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
