Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.4 Milling
Turning
452 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Parameter
Description
(only for ShopTurn)
Clamp/release spindle (only for end face Y/peripheral surface Y)
The function must be set up by the machine manufacturer.
Machining
• ∇ (roughing)
• ∇∇∇ (finishing)
• ∇∇∇ edge (edge finishing, plane-by-plane or helical)
• Chamfering
Machining type
• Plane by plane
Solid machine circular pocket plane-by-plane
• Helical
Solid machine circular pocket helically
X0
Y0
Z0
(only for G code)
The positions refer to the reference point:
Reference point X
Reference point Y
Reference point Z
mm
mm
mm
X0 or L0
Y0 or C0
Z0 (only for Shop-
Turn)
Face C
: The positions refer to the reference point:
Reference point X or reference point length polar
Reference point Y or reference point angle polar
Reference point Z
mm
mm or
degrees
mm
CP
X0 or L0
Y0 or C0
Z0 (only for Shop-
Turn)
Face Y
: The positions refer to the reference point:
Positioning angle for machining area
Reference point X or reference point length polar
Reference point Y or reference point angle polar
Reference point Z
Degrees
mm
mm or
degrees
mm
Y0 or C0
Z0
X0
(only for ShopTurn)
Peripheral surface C
: The positions refer to the reference point:
Reference point Y or reference point length polar
Reference point Z
Cylinder diameter ∅
mm or de-
grees
mm
mm
C0
Y0
Z0
X0
(only for ShopTurn)
Peripheral surface Y
: The positions refer to the reference point:
Positioning angle for machining surface
Reference point Y
Reference point Z
Reference point X
Degrees
mm
mm
mm
