Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.4 Milling
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
459
Parameter
Description
Unit
UZ
Depth finishing allowance (tool axis) - (only for ∇ and ∇∇∇)
mm
W1 Width of blank spigot (important for determining approach position) - (only for ∇
and ∇∇∇)
mm
L1 Length of blank spigot (important for determining approach position) - (only for ∇
and ∇∇∇)
mm
FS
Chamfer width for chamfering - (for chamfering only)
mm
ZFS
Insertion depth of tool tip (abs or inc) - (for chamfering only) mm
* Unit of feedrate as programmed before the cycle call
Parameters in the "Input simple" mode
G code program parameters
ShopTurn program parameters
Input
• simple
Milling direction
T
Tool name
RP
Retraction plane
mm
D
Cutting edge number
F Feedrate * F Feedrate mm/min
mm/rev
S / V Spindle speed or constant
cutting rate
rpm
m/min
Parameter
Description
FZ
Depth infeed rate (only for ∇ and ∇∇∇)
*
Machining
surface (only for
ShopTurn)
• Face C
• Face Y
• Peripheral surface Y
Position (only for
ShopTurn)
• At the front (face)
• At the rear (face)
• Outside (peripheral surface)
• Inside (peripheral surface)
(only for ShopTurn)
Clamp/release spindle (only for end face Y/peripheral surface Y)
The function must be set up by the machine manufacturer.
Machining The following machining operations can be selected:
• ∇ (roughing)
• ∇∇∇ (finishing)
• Chamfering
