Programming technology functions (cycles)
9.4 Milling
Turning
458 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Parameter
Description
Unit
Machining position
• Single position
Mill rectangular pocket at the programmed position (X0, Y0, Z0).
• Position pattern
Position with MCALL
X0
Y0
Z0
(only for G code)
The positions refer to the reference point:
Reference point X – (only for single position)
Reference point Y – (only for single position)
Reference point Z
mm
mm
mm
X0 or L0
Y0 or C0
Z0
(only for ShopTurn)
Face C:
The positions refer to the reference point:
Reference point X or reference point length polar – (only for single position)
Reference point Y or reference point angle polar – (only for single position)
Reference point Z – (only for single position)
mm
mm
mm
CP
X0 or L0
Y0 or C0
Z0
(only for ShopTurn)
Face Y:
The positions refer to the reference point:
Positioning angle for machining area – (only single position)
Reference point X or reference point length polar – (only for single position)
Reference point Y or reference point angle polar – (only for single position)
Reference point Z – (only for single position)
Degrees
mm
mm or de-
grees
mm
Y0 or C0
Z0
X0
(only for ShopTurn)
Peripheral surface C:
The positions refer to the reference point:
Reference point Y or reference point angle polar – (only for single position)
Reference point Z – (only for single position)
Cylinder diameter ∅ – (only for single position)
mm or de-
grees
mm
mm
C0
Y0
Z0
X0
(only for ShopTurn)
Peripheral surface Y:
The positions refer to the reference point:
Positioning angle for machining surface – (only for single position)
Reference point Y – (only for single position)
Reference point Z – (only for single position)
Reference point X – (only for single position)
Degrees
mm
mm
mm
W
Width of spigot
mm
L
Length of spigot
mm
R
Corner radius
mm
α0
Angle of rotation
Degrees
Z1
Spigot depth (abs) or depth relative to Z0 or X0 (inc) - (only for ∇ and ∇∇∇) mm
DZ
Maximum depth infeed - (only for ∇ and ∇∇∇)
mm
UXY
Plane finishing allowance for the length (L) and width (W) of the rectangular spigot.
Smaller rectangular spigot dimensions are obtained by calling the cycle again and
programming it with a lower finishing allowance. - (only for ∇ and ∇∇∇)
mm
