Siemens SINUMERIK 828D User Manual

Programming technology functions (cycles)
9.4 Milling
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
463
Procedure
1.
The part program or ShopTurn program to be processed has been cr
e-
ated and you are in the editor.
2.
Press the "Milling" softkey.
3.
Press the "Multi
-edge spigot" and "Circular spigot" softkeys.
The "Circular Spigot" input window opens.
Parameters in the "Input complete" mode
G code program parameters
ShopTurn program parameters
Input
• Complete
PL
Machining plane T Tool name
Milling direction D Cutting edge number
RP Retraction plane mm F
Feedrate mm/min
mm/tooth
SC Safety clearance mm S / V
Spindle speed or constant cut-
ting rate
rpm
m/min
F
Feedrate
*
Parameter
Description
Unit
FZ
(only for G code)
Depth infeed rate *
Machining
surface
(only for Shop-
Turn)
• Face C
• Face Y
• Peripheral surface C
• Peripheral surface Y
Position
(only for Shop-
Turn)
• At the front (face)
• At the rear (face)
• Outside (peripheral surface)
• Inside (peripheral surface)
