Programming technology functions (cycles)
9.4 Milling
Turning
464 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
(only for Shop-
Clamp/release spindle (only for end face Y/peripheral surface Y)
The function must be set up by the machine manufacturer.
Machining
The following machining operations can be selected:
• ∇ (roughing)
• ∇∇∇ (finishing)
• Chamfering
Machining posi-
tion
• Single position
Mill circular spigot at the programmed position (X0, Y0, Z0).
• Position pattern
X0
Y0
Z0
The positions refer to the reference point:
Reference point X – (only for single position)
Reference point Y – (only for single position)
Reference point Z
mm
mm
mm
X0 or L0
Y0 or C0
Z0
(only for Shop-
The positions refer to the reference point:
Reference point X or reference point length polar – (only for single position)
Reference point Y or reference point angle polar – (only for single position)
Reference point Z – (only for single position)
mm
mm or de-
grees
mm
CP
X0 or L0
Y0 or C0
Z0
(only for Shop-
The positions refer to the reference point:
Positioning angle for machining area – (only single position)
Reference point X or reference point length polar – (only for single position)
Reference point Y or reference point angle polar – (only for single position)
Reference point Z – (only for single position)
Degrees
mm
mm or de-
grees
mm
Y0 or C0
Z0
X0
(only for Shop-
The positions refer to the reference point:
Reference point Y or reference point angle polar - (only for single position)
Reference point Z - (only for single position)
Cylinder diameter ∅ – (only for single position)
mm or de-
grees
mm
mm
