Siemens SINUMERIK 828D - Page 471

Programming technology functions (cycles)
9.4 Milling
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
471
Parameter
Description
Unit
FS
Chamfer width for chamfering - (for chamfering only)
mm
ZFS Insertion depth of tool tip (abs or inc) - (for chamfering only) mm
%
* Unit of feedrate as programmed before the cycle call
Parameters in the "Input simple" mode
G code program parameters
ShopTurn program parameters
Input
• simple
Milling direction
T
Tool name
RP
Retraction plane
mm
D
Cutting edge number
F Feedrate * F Feedrate mm/min
mm/rev
S / V Spindle speed or constant
cutting rate
rpm
m/min
Parameter
Description
Machining
surface
• Face C
• Face Y
Position
(only for ShopTurn)
• Front
• Back
(only for ShopTurn)
Clamp/release spindle (only for face C)
The function must be set up by the machine manufacturer.
Machining The following machining operations can be selected:
• ∇ (roughing)
• ∇∇∇ (finishing)
• ∇∇∇ edge (edge finishing)
• Chamfering
X0 (only G code)
Y0 (only G code)
Z0
The positions refer to the reference point:
Reference point X
Reference point Y
Reference point Z
mm
mm
mm
∅
Diameter of blank spigot
mm
N
Number of edges
SW or L
Width across flats or edge length
mm
