Programming technology functions (cycles)
9.4 Milling
Turning
472 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Parameter
Description
R1 and FS1
Rounding radius or chamfer width
Z1 Multi-edge depth (abs) or depth in relation to Z0 (inc) - (only for ∇, ∇∇∇ and ∇∇∇ edge) mm
DXY
• Maximum plane infeed
• Maximum plane infeed as a percentage of the milling cutter diameter
- (only for ∇ and ∇∇∇)
mm
%
DZ Maximum depth infeed – (only for ∇ and ∇∇∇) mm
UXY
Plane finishing allowance - (only for ∇, ∇∇∇ and ∇∇∇ edge).
mm
UZ
Depth finishing allowance (only for ∇ and ∇∇∇)
mm
FS
Chamfer width for chamfering - (for chamfering only)
mm
ZFS
Insertion depth of tool tip (abs or inc) - (for chamfering only)
mm
* Unit of feedrate as programmed before the cycle call
Hidden parameters
The following parameters are hidden. They are pre-assigned fixed values or values that can
be adjusted using setting data.
Parameter
Description
Value
Can be set in SD
PL (only for G
code)
Machining plane
Defined in MD
52005
SC (only for G
code)
Safety clearance 1 mm x
Machining
position (only for G
code)
Mill multi-edge at the programmed position (X0, Y0, Z0). Single posi-
tion
α0
Angle of rotation
0°
Machine manufacturer
Please refer to the machine manufacturer's specifications.
